High Gloss Wood Grain Steel Coil
High Gloss Wood Grain Steel Coil
Glossy Wood Aesthetics, Built to Last
| Substrate | Galvalume / Galvanized Steel (GL / GI) |
| Surface Design | High Gloss Wood Grain Pattern (Printed) |
| Coating Thickness | Top: 15–25 µm | Back: 5–12 µm |
| Thickness Range | 0.12 – 1.2 mm |
| Coil Width | 600 – 1250 mm |
Corrosion-Resistant Core
Metallic substrate base helps protect the sheet against rust and ambient moisture.
Vibrant Wood Aesthetics
Clear varnish topcoat enhances timber grain clarity with a reflective gloss finish.
Formable Paint Layer
Quality primer treatment helps maintain pattern integrity during roll forming.
Flexible Pattern Options
Multiple wood grain designs, gloss levels, and sheet sizes available to match local markets.
Product Specifications
| Parameter | Details |
|---|---|
| Product Name | High Gloss Wood Grain Steel Coil (Patterned PPGL/PPGI) |
| Substrate Material | Galvalume Steel (GL) / Galvanized Steel (GI) |
| Standard Compliance | ASTM A755, EN 10169, JIS G3322 |
| Surface Finish | High Gloss Clear Varnish, Printed Wood Texture (70°–85° Gloss Units) |
| Thickness Range | 0.12 – 1.2 mm |
| Width Range | 600 – 1250 mm |
| Zinc/Aluzinc Coating | AZ30 – AZ150 g/m² or Z30 – Z275 g/m² |
| Coil Inner / Outer Diameter | ID: 508 / 610 mm; OD: Max 1500 mm |
| Coil Weight | 3 – 8 Metric Tons per coil (Customizable) |
Quality Control & Shipping Case
Precision roller printing ensures stable pattern alignment without blur or misregistration.
Every batch undergoes wood grain matching tests to ensure sharp and consistent details.
Waterproof paper, protective plastic film, and steel strapping prevent transit damage.
Efficient manufacturing and quick documentation keep your order on schedule.
Buyer Concern & FAQ
Q1: What is PPGI.LTD’s High Gloss Wood Grain Steel Coil and its key design features?
PPGI.LTD is a direct manufacturer of High Gloss Wood Grain Steel Coils, engineered with high-precision multi-color roller printing and a smooth, ultra-clear high-gloss protective topcoat (gloss level ≥ 60%) over galvanized or galvalume steel substrates. Specifically designed for luxury door panels, interior decorative walls, and home appliances, our pre-painted high-gloss wood steel delivers vivid pattern depth, easy cleaning, and robust corrosion resistance.
Q2: What is the main difference between High Gloss Wood Grain Steel Coils and matt wood finishes?
High Gloss Wood Grain Steel Coils feature a smooth, reflective clearcoat that accentuates vibrant color contrast and intricate wood grain details for a polished, modern look. In contrast, matt finishes offer a non-reflective, subtle timber texture suited for glare-sensitive exterior facades.
Q3: How does PPGI.LTD protect the smooth finish of High Gloss Wood Grain Steel Coils during processing?
We apply high-hardness flexible clearcoats with superior anti-scratch properties and tight coating adhesion (T-bend ≤ 2T). This ensures the high-gloss surface resists micro-abrasions, cracking, or gloss loss during roll forming, shearing, bending, and assembly.
Q4: Can a protective film be applied to High Gloss Wood Grain Steel Coils during manufacturing?
Yes. We can apply self-adhesive PE protective film (30–80 microns) with custom printed branding. Formulated specifically for smooth mirror-like surfaces, it protects the gloss finish from dust, oil stains, and transit scratches without leaving residue upon removal.
Q5: What are the primary applications for High Gloss Wood Grain Steel Coils?
High Gloss Wood Grain Steel Coils are widely used in indoor decorative wall paneling, modular ceiling systems, high-end security door skins, elevator cabin interiors, and home appliance casing where a premium, highly detailed wood appearance is desired.
